Description

Permeability Apparatus (Single Cell Model)

One of the strength tests of concrete is utilized to know the penetrability of water through the test. Permeability gear is utilized for deciding the penetrability of cement mortar and concrete tests of 15 cm cube shapes cast within the research facility.
Specification:
The concrete permeability apparatus consists of a brass/gunmetal cell of Square/Round cross-section mounted on a stand and a pressure chamber is connected to the cell through copper tubing and T-connector mounted on the stand with sleeve packed valve and rubber hose pipe with end connections.The cell assembly comprises of one base plate, one metal funnel, and one top plate. The pressure chamber is fitted with a pressure regulator which helps in regulating the pressure from 0-15kg/cm sq. Gauge is for indicating the pressure in the cell. A foot pump and a pressure tube is supplied to develop pressure in the chamber. The apparatus is supplied with a measuring cylinder 500 cc to measure percolated quantity to water. Pressure can also be applied; by a pressure air line or by a compressor which can be supplied at an extra cost..

Manufactures,Suppliers,Exporters of Permeability Apparatus (Single Cell Model) for Testing Equipment . Contact us to get Superior Quality designed Permeability Apparatus (Single Cell Model) For Testing Equipment for schools, colleges, research facilities and different businesses.We acknowledge bulk orders for government tenders for worldwide.,SOUTH AFRICA, EUROPE,INDIA,USA,AUSTRALIA,CANADA,UAE,NEW ZEALAND,UK.
