Description

Jolting Apparatus

• This device comprises of a rectangular table unbending associated by two back arms to a shaft at a even separate of 800 mm from the middle of the table
• There could be a anticipating carry with a plane confront on the upper face of the table underneath which may be a halt with a adjusted upper surface
• The table can be raised and permitted to drop openly on the halt by a cam which is associated to a engine and gearbox through a V belt an pulleys
• The cam turns at a rate of 60 Rev Min.
• A stroke counter fitted with small scale switch is given which stops the machine after 60 Jolts
• Locating pins are given for mounting the shape compartments on the table • The shape surmounted by the container can be clamped inflexibly to the table
• Supplied total with shape and hopper
• Suitable for operation on 230 Volts Single Stage A.C. Supply
• A Advanced preset counter can be provided at an additional cost
• Steel form with base plate having three compartments each having 40 mm x 40 mm x 160 mm inside measurements.

Manufactures,Suppliers,Exporters of Jolting Apparatus for Testing Equipment . Contact us to get Superior Quality designed Jolting Apparatus For Testing Equipment for schools, colleges, research facilities and different businesses.We acknowledge bulk orders for government tenders for worldwide.,SOUTH AFRICA, EUROPE,INDIA,USA,AUSTRALIA,CANADA,UAE,NEW ZEALAND,UK.
